After a lateral release in position SKI, first push the pin lever upward by hand and the system will automatically return to the home position as shown on the picture or in the video. Then you can open the binding to step in.

After a lateral release in position SKI, first push the pin lever upward by hand and the system will automatically return to the home position as shown on the picture or in the video. Then you can open the binding to step in.

Remove the snow around the release lever, as shown in the video, so that it can be freely moved.

Check according the video, if any snow has accumulated under the automatic heel unit. In this case, it would not be possible to switch to the WALK mode.

There is natural abrasion on moving parts. Therefore, they have to be greased with a water-repellent and cold-resistant grease (-30° C).
If you can’t reach certain moving parts, this is due to a closed system and the grease which was put on the binding mounting doesn’t get off.
After greasing remove the excessive grease with a damp cloth.

Lubricate the Tecton at the heel plate ski brake and the heel according to the picture or video.
We recommend having the lubrification made by a specialist dealer.

Lubricate the Vipec Evo at the heel the heel plate ski brake and the Comfort Levers 1&2 according to the picture or video.
We recommend having the lubrification made by a specialist dealer.

Lubricate the Xenic at the heel the heel plate ski brake and the Comfort Lever according to the picture and video.
We recommend having the lubrification made by a specialist dealer dealer.

Yes, the heel unit of the Tecton can be moved backward or forward by 12.5 mm from the middle. We recommend to have the boot adjusted by a specialist dealer.
Caution: Because of the difference in the length of the boot's sole, the DIN value must be recalculated and reset to ensure a reliable release.

Yes, the heel jaw of the Vipec Evo can be moved backward or forward by 12.5 mm from the middle. We recommend to have the boot adjusted by a specialist dealer.
Caution: Because of the difference in the length of the boot's sole, the DIN value must be recalculated and reset to ensure a reliable release.

Yes, the heel jaw of the Xenic can be moved backward or forward by 12.5 mm from the middle. We recommend to have the boot adjusted by a specialist dealer.
Caution: Because of the difference in the length of the boot's sole, the DIN value must be recalculated and reset to ensure a reliable release.

Yes. Boots with Grip-Walk soles meet the standard ISO 23223 are compatible with Scout.

Yes.
Boots with Grip-Walk soles meet the standard ISO 23223 are compatible with Tecton.

Yes.
Boots with Grip-Walk soles meet the standard ISO 23223 are compatible with Vipec Evo.

Yes.
Boots with Grip-Walk soles meet the standard ISO 23223 are compatible with Xenic.

No. You can NOT modify a Xenic with a middle heel elevator to a Xenic plus with a low and a high heel elevator.

For downhill skiing, you have to remove the crampons. Otherwise the bindings are unable to release laterally.

Replacement parts are available for approx. 8 years after the last season the bindings were sold. Please send us a pictures of your binding that clearly show the defect and the model.
We will help.

Yes, instead of a ski brake you can use the easy to mount safety leash from our available accessories. We recommend using all bindings with at least one safety device.

For safety reasons we recommend using a ski brake.
Since ski touring boots do not have a secure receptacle for safety straps, we recommend using the safety strap in combination with a ski brake.
A safety leash is available as accessories (picture). They should be mounted by a specialist dealer.

When climbing uphill the Xenic is blocked at the toe as are all pin bindings with lateral release in the heel.
Going downhill the Xenic provides secure support and will not release until the set force is reached. An impact from below can't open the front binding system. It does not have to be blocked.
Blocking the release function of a binding for downhill skiing may cause considerable injuries.

Alpine boots for children are compatible with the Scout only when you see the letter A on the sole of the boot (approx. from Mondo 22.0 on). This means that the boot was built in accordance with DIN ISO 5355 (alpine boots for adults). If you see the letter C, they are made according the standrads of children boots and are not compatible.

The crampon is to fix at the Scout accoring to the video.

The crampon is to fix at the Tecton accoring to the video.

The crampon is to fix at the Vipec Evo accoring to the Video.

The crampon is to fix at the Xenic accoring to the video.

To enjoy the skitour it is important to put on the summit the Scout on position SKI, BEFORE you take off the skin.

To enjoy the skitour it is important to put on the summit the Tecton on position SKI, BEFORE you take off the skin.

To enjoy the skitour it is important to put on the summit the Vipec Evo on position SKI, BEFORE you take off the skin.

To enjoy the skitour it is important to put on the summit the Xenic on position SKI, BEFORE you take off the skin.

After the specialist dealer checked the length adjustment (boot) and the DIN-setting (person), he tests with the parameters on a testing equipment according to DIN ISO 11110 the lateral and frontal release.

The climbing aid is easy to change with the ski pole.

The Comfort Lever 1 and 2 (climbing aids) are easy to change with the ski pole.

The Comfort Lever 1 and 2 (climbing aids) are easy to change with the ski pole.

The Comfort Lever (climbing aid) is easy to change with the ski pole.

To ensure optimal function and safety, Fritschi recommends to have a specialist dealer mount the bindings, adjust them to the boots and change the DIN settings.

Regular care and proper storage as well as an annual binding check of the binding by a specialist dealer ensure a reliable function and a long service life.

Make sure that you activate it in the first walk level, as shown on the picture or video. Position the tip of the ski pole on the retaining edge of the blade. Lightly tap the top of the ski pole with your hand to release the hold. The blade can then be turned backwards with the basket of the ski pole. The function is not ensured until the binding is lowered to the ski and the blade audibly snaps in.
The crampons have to be mounted in order to be activated or deactivated.

Regular care and an annual inspection by a specialist dealer reduce the risk of a defect to a minimum.

Move the climbing aid backward and use it as a lever to turn the heel by 180°. Do not push the ski brake downward because it automatically locks with the first step. See picture or video.

For an optimal step-in beat the snow out of the boot sole or remove it with the ski pole. IMPORTANT not to hit the boot over the binding.

For an optimal step-in beat the snow out of the boot sole or remove it with the ski pole. IMPORTANT not to hit the boot over the binding. Make sure that the boot inserts are free of stones and dirt. Remove the snow front the front and heel unit of the binding.

For an optimal step-in beat the snow out of the boot sole or remove it with the ski pole. IMPORTANT not to hit the boot over the binding. Make sure that the boot inserts are free of stones and dirt. Remove the snow front the front and heel unit of the binding.

For an optimal step-in beat the snow out of the boot sole or remove it with the ski pole. IMPORTANT not to hit the boot over the binding. Make sure that the boot inserts are free of stones and dirt. Remove the snow front the front and heel unit of the binding.

For an optimal step-out open the release lever with the ski pole and IMPORTANT don't open with the ski.

For an optimal step-out open the front lever with the ski pole and IMPORTANT don't open with the ski.

For an optimal step-out open the front lever with the ski pole and IMPORTANT don't open with the ski.

For an optimal step-out open the front lever with the ski pole and IMPORTANT don't open with the ski.

According to the video.

According to the video.

According to the video.

According to the video.

The warranty period is two years. Instructions and conditions are provided in the Warranty Certificate section of your user manual.
If you register your bindings the warranty period will be extended by one year.
For the necessary serial numbers, please see the instruction manual or, in case of Alubar models, the bottom of the automatic heel unit.

Make sure your bindings are clean and dry to avoid corrosion.
To relieve the spring, close the front units (if existing) and heel units; that means put them on position SKI.
If your DIN-value is higher than 9, put it on a minimum.
See video.

Make sure your bindings are clean and dry to avoid corrosion.
To relieve the spring, close the heel units; that means put them on position SKI.
See video.

Make sure your bindings are clean and dry to avoid corrosion.
To relieve the spring, close the front units and heel units; that means put them on position SKI.
If your DIN-value is higher than 9, put it on a minimum.
See video.

Make sure your bindings are clean and dry to avoid corrosion.
To relieve the spring, close the front units; that means put them on position SKI.
If your DIN-value is higher than 9, put it on a minimum.
See video.

Make sure your bindings are clean and dry to avoid corrosion.
To relieve the spring, close the front units; that means put them on position SKI.
See video.

By one of Fritschi's trained specialist dealer. In addition to compatibility with the boot, proper mounting, adjustment and settings are required for an optimal function. Professional mounting is also required for warranty claims and product liability. These services may be subject to charge.

If you have an Alpine- (DIN ISO 5355) or Gripwalk boots (DIN ISO 23223), you can request a Step-in Clip with the contact form.

Important: With all other soles like touring soles with more rubber and rocker, the step-out and the lateral release are negatively affected if a step-in clip is mounted.

If you have an Alpine- (DIN ISO 5355) or Gripwalk boots (DIN ISO 23223), you can request a Step-in Clip with the contact form.

Important: With all other soles like touring soles with more rubber and rocker, the step-out and the lateral release are negatively affected if a step-in clip is mounted.

Fritschi bindings have a very reliable release, even with settings in the lower range. For DIN settings below 4 we recommend the Scout 11 and as pin binding the Xenic 7 (one heel elevator) with DIN setting range 3 - 7. Overview.

No, but the lateral release is significantly inhibited. In climbing, the boot will be released in an emergency if substantial force is applied.

No, but the lateral release is significantly inhibited. In climbing, the boot will be released in an emergency if substantial force is applied.

Yes, it meets the DIN ISO standards 13992 and 9462 for touring and alpine bindings and for touring ski boots according to DIN ISO 9523 and alpine ski boots according to DIN ISO 5355.
Certificate.

No, but the Tecton meets almost all criteria.
Many boots with inserts do not meet the standards and so a TÜV certificate does not correspond to the practice. Safety is priority for Fritschi and therefore all models are tested according to the ISO standard 13992 for ski touring bindings. As well as our production and work processes are periodically inspected by TÜV.

No, but the Vipec Evo meets almost all criteria.
Many boots with inserts do not meet the standards and so a TÜV certificate does not correspond to the practice. Safety is priority for Fritschi and therefore all models are tested according to the ISO standard 13992 for ski touring bindings. As well as our production and work processes are periodically inspected by TÜV.

No, but the Xenic meets many criterias.
Many boots with inserts do not meet the standards and so a TÜV certificate does not correspond to the practice. Safety is priority for Fritschi and therefore all models are tested according to the ISO standard 13992 for ski touring bindings. As well as our production and work processes are periodically inspected by TÜV.

Contact your specialist dealer. He will obtain the replacement parts, handle the repair and even process the warranty claim, if necessary.

No. The DIN-value is calculated: with the following parameters: skier's weight, height, age, boot sole length and type of skier.
IMPORTANT: the DIN-value is only an approximate value and might be corrected by one up or down after a bad release.

When you change from the ski to the walk position in back, it is important to do it in two steps as shown on the picture or video:
1.   Turn the heel and use the climbing aid as a lever (do not touch the ski stopper)
2.   Ski brake locks automatically when you take the first step

With the standard guiding plate 25 mm the adjustment of the binding is 12.5 mm to the front and 12.5 mm to the back of the mounting point.

If you need more adjustment range, you'll get a longer guiding plate of 60 mm at the sport shop.

With the standard guiding plate 25 mm the adjustment of the binding is 12.5 mm to the front and 12.5 mm to the back of the mounting point.

If you need more adjustment range, you'll get a longer guiding plate of 60 mm at the sport shop.

With the standard guiding plate 25 mm the adjustment of the binding is 12.5 mm to the front and 12.5 mm to the back of the mounting point.

If you need more adjustment range, you'll get a longer guiding plate of 60 mm at the sport shop.

One pair of Scout with ski brake weighs 1,78 kg.

One pair of Tecton with ski brake weighs 1,2 kg.

One pair of Vipec Evo with ski brake weights 1,1 kg.

One pair of Xenic without ski brake weighs 560 g;
with ski brake 650 g.
The Xenic plus (two heel elevators) weighs 20 g more.

The registration extends the warranty period of your Fritschi bindings by one year to three years.
For the necessary serial numbers, please see the instruction manual or, in case of Alubar models, the bottom of the automatic heel unit.

In this unusual case, the colored bow is removable to position the boot when you step in according to the video.
Fritschi recommends in any event to have it removed by a specialist dealer and have the compatibility checked according to the 4-point check.

Check whether the ski brake touches the edge of the ski. If so, it has to be replaced with a wider ski brake.
If the ski brake is wide enough, lightly lubricate it at the contact points, as shown in the video.

Check whether the ski brake touches the edge of the ski. If so, it has to be replaced with a wider ski brake.
If the ski brake is wide enough, lightly lubricate it at the contact points, as shown in the video.

Check whether the ski stopper touches the edge of the ski. If so, it has to be replaced with a wider stopper.
If the ski stopper is wide enough, lubricate it at the contact points with the step plate, as shown in the video.

The DIN settings define the force at which the binding is supposed to release. It is determined according to DIN ISO shown in this table and based on the skier's weight, height, the length of the boot's sole, the age and the type of skier you are. On the internet you'll find different DIN calculators; example.
We recommend having the settings adjusted and checked by a specialist dealer.

Check according to the video whether the sole of the boot and the inserts are free of ice and snow.
Caution: Never clean ice or snow on the front jaw as this could damage the binding.
Tip: After stepping in, move the boot up and down two or three times to push any remaining snow and ice out of the inserts.

As shown in the video first clean the snow out of the automatic front unit and make sure that the tip of your toe does not depress the step-in trigger when you push down the Easy Switch Toe.

The binding releases under the effect of the selected force. If you repeatedly feel that the binding should have released or releases too early, it is necessary to check whether the DIN settings have been correctly determined or set. further is to check the adjustment of the binding to the boot.
We recommend to check the setting by a specialist dealer.

Knock out and remove snow or ice according to the video.

Remove the snow from the binding, especially under the Easy Switch Toe, as shown in the video.

Knock out and remove snow or ice according to the video.

Check whether the sole of the boot and the inserts are free of ice and snow.
Caution: Never clean ice or snow on the front jaw as this could damage the binding.
Tip: After stepping in, move the boot up and down two or three times to push any remaining snow and ice out of the inserts.

Open first the heel unit, as shown in the video to prevent any contact pressure acting on the system. Then the toe unit opens as well.

To ensure optimal function and safety, Fritschi recommends to have the bindings checked and adjusted, if necessary, by a specialist dealer every year before the winter season begins.
The enduser can tighten the mounting screws, lubricate the moving parts and sliding surfaces with a commercially available lubricant and check all functions of the binding.

To ensure optimal function and safety, Fritschi recommends to have the bindings checked and adjusted, if necessary, by a specialist dealer every year before the winter season begins.
The enduser can tighten the mounting screws, lubricate the moving parts and sliding surfaces with a commercially available lubricant and check all functions of the binding. See video.

To ensure optimal function and safety, Fritschi recommends to have the bindings checked and adjusted, if necessary, by a specialist dealer every year before the winter season begins.
The enduser can tighten the mounting screws, lubricate the moving parts and sliding surfaces with a commercially available lubricant and check all functions of the binding. See video.

To ensure optimal function and safety, Fritschi recommends to have the bindings checked and adjusted, if necessary, by a specialist dealer every year before the winter season begins.
The enduser can tighten the mounting screws, lubricate the moving parts and sliding surfaces with a commercially available lubricant and check all functions of the binding. See video.

The length of the boot's sole is what determines the choice. For an optimal standing position on the ski, the smallest possible binding size should be selected.
Size SM: Boot sole 260 - 315 mm
Size ML: Boot sole 285 - 340 mm
Size XL: Boot sole 330 - 370 mm

To ensure optimal function and safety, Fritschi recommends to have the bindings checked and adjusted, if necessary, by a specialist dealer every year before the winter season begins.
If you have new boots or if your weight has changed, the bindings have to be readjusted and/or the DIN settings have to be changed.

To ensure optimal function and safety, all repairs are coordinated and completed by a specialist dealer.

For safety reasons, we do not provide drilling templates to private individuals. To ensure optimal function, compatibility with the boot and to meet the warranty requirements, we recommend having the binding mounted, adjusted to the boot and set by a trained specialist dealer.

Our Website has interesting informations about each binding in text, picture and video. To this show our Fritschi specialist dealers the bindings in their sportshop.

Compact Modul: The Compact Module integrates various Fritschi technologies and ensures that they work reliably under all conditions.

Four optimal walk mode levels: Change between four optimally synchronized walk mode levels with maximum ease using the ski pole.

Activatable crampons: The Axion crampon is fixed in place before the tour. The blade can be flipped down with the pole if required.

Pictures of characteristics

Lateral TOE release: DIN value setting and lateral toe release, where the forces act in case of fall.

Exclusive rails: The rail engages in the heel of the boot, secures it at the center and prevents lateral loss of power.

Direct Traction: The heel piece presses the sole of the boot firmly against the heel plate, which is directly connected with the ski.

Pictures of characteristics

Lateral TOE release: DIN value setting and lateral toe release, where the forces act in case of fall.

Fixed heel unit: The rail engages in the heel of the boot, secures it at the center and prevents lateral loss of power.

Easy Handling: Switching from downhill to uphill mode and vice versa is very simple without having to step out of the binding.

Pictures of characteristics

Horizontally sliding pin levers: Secure hold and prevention of pre-release when downhill skiing without locking the system.

Extra wide support: The power is transferred directly to the ski via the extra-wide support at the heel.

10 mm length compensation: Consistent release at set DIN values due to the length compensation for the flexing ski.

Images caractéristiques

Current:
Tecton 10: metallic blue, bordeaux-violet and black
Tecton 13: copper, yellow-green and black.

Color Clips for older Tecton on request

Current: blue, linden green and black.
Color Clips for older Vipec Evo on request

The crampon Standard 78 or 100 mm, whereat xx indicates the middle ski width at which the crampons sure fits.

Unfortunately we don't have these crampons available since 2017.

The crampon Axion.
This activable crampon can be chosen in two widths: 86 / 110 mm
Whereat xx indicates always the middle ski width at which the crampons sure fits.

The crampon Vipec/Tecton.
It also fits the Vipec Evo and is easy to use.
This crampon can be chosen in three widths: 90 / 100 / 115 mm, whereat xx indicates always the middle ski width at which the crampons sure fits.

The crampon Vipec/Tecton.
It also fits the Tecton and is easy to use.
This crampon can be chosen in three widths: 90 / 100 / 115 mm, whereat xx indicates always the middle ski width at which the crampons sure fits.

The crampon Xenic.
Other brands of crampons with a similar operating method may possibly be used.
This crampon can be chosen in three widths: 85 / 95 / 105 mm, whereat xx indicates always the middle ski width at which the crampons sure fits.

DIN 3 till 11

Tecton 10: DIN 5 till 10
Tecton 13: DIN 5 till 13

DIN 4 till 12

Xenic 7:              DIN 3 till 7
Xenic (plus) 10: DIN 4 till 10
Xenic plus 12:    DIN 6 till 12

The Scout is compatible with ski boots according to DIN ISO 9523 for touring ski boots and DIN ISO 5355 for alpine ski boots. See list (current models).
Fritschi recommends having the compatibility checked by a specialist dealer.

Basically all models with inserts and an adequate retaining edge to hold the boot on the heel are compatible according to the list (current models).
Fritschi recommends to check the compatibility with the 4-items to be checked by a specialist dealer.

Basically all models with inserts and an adequate retaining edge to hold the boot on the heel are compatible according to the list (current models).
Fritschi recommends to check the compatibility with the 4-items to be checked by a specialist dealer.

Basically all models with inserts and an adequate retaining edge to hold the boot on the heel are compatible according to the list (current models).
Fritschi recommends to check the compatibility with the 4-items to be checked by a specialist dealer.

With ski brake 80 / 90 / 100 / 115 mm,
whereat xx indicates always the middle ski width at which the ski brake sure fits.

With ski brake 80 / 90 / 100 / 110 / 120 mm,
whereat xx indicates always the middle ski width at which the ski brake sure fits.

With ski brake 80 / 90 / 100 / 110 / 120 mm,
whereat xx indicates always the middle ski width at which the ski brake sure fits.

Without (only with one heel elevator) or with ski brake 75 / 85 / 95 / 105 mm,
whereat xx indicates always the middle ski width at which the ski brake sure fits.
